CE
|
Model |
15LB | 30LB | 50LB |
Application |
||
|
Water Capacity(L) |
7 | 13 | 22 | |||
|
Standard Specification |
|
|
|
|||
|
Service Pressure(Bar) |
- |
15 | 15 |
BALLOON HELIUM GAS |
||
|
Test Pressure(Bar) |
- |
23 | 23 | |||
| 9‘’Latex Balloon Qty(PCS) |
- |
30 | 50 | |||
|
Optional Specification |
|
|
|
|||
|
Service Pressure(Bar) |
27 | 30 | 27 | 30 | - | |
|
Test Pressure(Bar) |
40.5 | 45 | 40.5 | 45 | - | |
|
9‘’Latex Balloon Qty(PCS) |
30 | 30 | 50 | 50 | - | |
DOT 39/KGS
|
Model |
15LB | 30LB | 50LB |
Application |
||
|
Water Capacity(L) |
7 |
13 | 22 | |||
|
Standard Specification |
|
|
|
|||
|
Service Pressure(Mpa) |
2.21 |
1.8 | 1.8 |
BALLOON HELIUM GAS |
||
|
Test Pressure(Mpa) |
2.76 |
2.24 | 2.24 | |||
| 9‘’Latex Balloon Qty(PCS) |
22 |
30 | 50 | |||
|
Optional Specification |
|
|
|
|||
|
Service Pressure(Mpa) |
2.76 | 2.76 | - | |||
|
Test Pressure(Mpa) |
3.45 | 3.45 | - | |||
|
9‘’Latex Balloon Qty(PCS) |
30 | 50 | - | |||
PACKING DETAILS
|
item |
water capacity | packing size(mm) | 20GP(PCS) without pallet | 40HQ(PCS) without pallet | 20GP(PCS) with pallet | 40HQ(PCS) with pallet |
| 1# | 7L | 195*195*370 | 2000 | 4800 | 1650 | 4095 |
| 2# | 13L | 245*245*425 | 1110 | 2650 | 900 | 2350 |
| 3# | 22L | 305*305*452 | 650 | 1620 | 540 | 1200 |
| 4# | 12.3L | 245*245*470 | 980 | 2350 | 800 | 2000 |
| 5# | 14.3L | 245*245*570 | 810 | 1950 | 680 | 1600 |
| 6# | 5L | 195*195*305 | 2330 | 5700 | 1950 |
5040 |
